18W sunpower flexible solar panels
18W sunpower flexible solar panels
      Basic parameters
  • ¡¼Name¡½         18W sunpower flexible solar panels
  • ¡¼Category¡½    Solar Panels
  • ¡¼Model¡½        DH18W-SP
  • ¡¼Brand¡½         DH-SOLAR
  • ¡¼Original¡½      Shenzhen
  • ¡¼Packing¡½      Carton+foam
      1. Please click here to download the product specifications.
    Performance and quality
    ITEM NO DH18W-SP
    MONO or POLY MONO
    Maximum power (Wp) 18W
    Maximum power voltage (V) 18.06
    Maximum power current (A) 0.98
    Open circuit voltage (V) 18.38
    Short circuit current (A)1.05
    Number of cells (Pcs) 36
    Size of module (mm)434*277*3
    Brand Name of Solar Cells Sunpower
    Maximum system voltage (V) 700
    Temperature coefficients of Isc (%)0.065+/-0.015%/¡ãC
    Temperature coefficients of Voc (%)-(2.23+/-0.1)mv/ ¡ãC
    Temperature coefficients of Pm (%)-(0.5+-0.05)/ ¡ãC
    Temperature coefficients of Im (%)+0.1/ ¡ãC
    Temperature coefficients of Vm (%)-0.38/ ¡ãC
    Temperature Range -40¡ãC~+85¡ãC
    Tolerance Wattage (e.g. +/-5%) +/-3%
    Surface Maximum Load Capacity60m/s(200kg/sq.m)
    Allowable Hail Load steel ball fall down from 1m height
    Weight per piece (kg) 0..29
    Length of Cables (mm) 500
    Cell Efficiency (%) >20.3%
    Module Efficiency (%) >17.2%
    Output tolerance (%) "+/-3%"
    Frame (Material, Corners, etc.)TPT backsheet, no frame,no glass
    Standard Test Conditions
    AM1.5  1000w/m 25¡ãC
    Warranty 5 years product warranty and 25years
    80% of power
    FF (%) 76.48%
    Packing5PCS/ CTN
    Unit Price ¡ª
